StarTech HDMI Over CAT5e/CAT6 Extender Kit 165' 50m ST121SHD50

FREE USPS Priority Shipping
Condition: New Open Box


-
+
$47.99

2 In Stock

posting

Condition: New Open Box



StarTech.com ST121SHD50 Specifications



HDMI Over CAT5/CAT6 Extender with Power Over Cable - 165ft


    At a Glance



    • Power Over Cable allows a single power source to operate the Transmitter and Receiver
    • Supports Cat5e or Cat6 Ethernet cabling (50m)
    • No software/drivers required
    • Supports HD resolutions up to 1080p (1920x1080)
    • Includes transmitter (local) and receiver (remote) units

      Overview




      The ST121SHD50 HDMI® over Cat5e/Cat6 Video Extender kit lets you extend HDMI video and audio by up to 165 feet (50 Meters) over dual Cat5e cables or dual Cat6 cables.For added versatility the kit features Power Over Cable andonly requires asingle power adapter that can be connected to either the Transmitter or Receiver.

      With support for High-Definition resolutions of up to 1920x1080 / 1080p and the accompanying digital audio, this cost-effective HD extender can easily be installed using new or existing Ethernet infrastructure wiring. For a convenient plug-and-play installation, the HDMI extender features built-in EDID monitor emulation, which ensures native resolution and maximum compatibility with your display or projector.

      For added flexibility and convenience, HDMI cables up to 32ft (10m) can be connected to both the local and remote units, which lets you extend your HDMI signal to even further distances.

      The HDMI extender kit offers a point-to-point digital signage solution right out of the box, including both local transmitter and remote receiver units, along with optional hardware that lets you mount the units as needed.Plus, withPowerOverCable, you can easily extend anHDMI signal inareas where access to power outlets is limited.

      This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support.

      More from the Manufacturer

        Certifications & Standards






        • CE
        • FCC



          Environmental Certification




          RoHS

          WEEE

          REACH






              Specifications


              Product Name HDMI Over CAT5/CAT6 Extender with Power Over Cable - 165ft
              Manufacturer Part Number ST121SHD50
              Product Type Video Extender Transmitter/Receiver
              Maximum Operating Distance 164.04 ft
              Number of Network (RJ-45) Ports 4
              Number of HDMI Inputs 1
              Media Type Supported Twisted Pair
              Number of Output Devices Supported 1
              Number of Input Devices Supported 1
              TAA Compliant Yes
              Connectivity Technology Wired
              Form Factor Rack-mountable
              Graphics Modes Full HD
              Environmentally Friendly Yes
              Maximum Video Resolution 1920 x 1080
              Twisted Pair Cable Standard Category 6
              Network (RJ-45) Yes
              Number of HDMI Outputs 1
              HDMI In Yes
              HDMI Out Yes
              Transmitter Height 0.80"
              Transmitter Width 2"
              Transmitter Depth 3.10"
              Receiver Height 0.80"
              Receiver Width 2"
              Receiver Depth 3.10"
              Transmitter Weight (Approximate) 11.08 oz
              Receiver Weight (Approximate) 11.08 oz
              Product Color Black
              Packaged Quantity Condition Kit
              Country of Origin Taiwan

              Product Material Aluminum
              Daisy Chain No
              Length 3.1"
              Input Voltage 110 V AC

              220 V AC

              Stock Details
              Manufacturer StarTech.com
              Manuf Part# ST121SHD50
