Panasonic WJ-NV200 Network Disk Recorder with DVD Drive 3 TB WJ-NV200V/3000T3

Panasonic WJ-NV200 Network Disk Recorder with DVD Drive 3 TB WJ-NV200V/3000T3

$30 Shipping
$199.99
Condition:  New Old Stock - New old stock. 60 Day Seller Warranty The Panasonic WJ-NV200 Network Disk Recorder with DVD Drive (3 TB) is a video decoder that includes a built-in 16-channel network disk recorder with face matching capability.


-
+
$199.99

3 In Stock

posting

Condition:  New Old Stock - New old stock. 60 Day Seller Warranty

The Panasonic WJ-NV200 Network Disk Recorder with DVD Drive (3 TB) is a video decoder that includes a built-in 16-channel network disk recorder with face matching capability.

H.264, MPEG-4, and JPEG multi formats
Up to 16 network cameras can be connected and recorded
Quick setup by automatic camera detection and simple setup wizard without the use of PC
"Referenced recording days" is automatically calculated by frame rate, image quality and HDD capacity
Simple mouse operation by new GUI can be done without the use of a PC
Quick intuitive search with calendar and timeline
Live images from up to 16 cameras can be displayed simultaneously
Supports the full HD output (HDMI) that can display recorded images and live images in high definition
Real Time Face matching function by matching registered face images with a face displayed on live images
Note:
Only channel 1; cameras supporting face detection function is required (WV-NP502, WV-SP305, or WV-SP306 is recommended)
Face matching alarm is notified by Buzzer / Email / Panasonic alarm / Terminal output / Indicator
Various alarm sources include 9x terminal inputs, 16x camera alarm, and Panasonic alarm protocol. Flexible alarm actions include alarm recording, email notification, alarm message, camera positioning, terminal output, Panasonic alarm protocol output, buzzer and indicator
Camera control features provides pan / tilt, zoom, focus, brightness, preset position, auto mode functions (depending on camera model)
Audio from the i-PRO network cameras can be recorded and played back, G.726 (ADPCM) 32 Kbps
Flexible playback controls enables go-to-date (Jump to specific time / date), go-to-last (Jump to 30 seconds before the record ends)
Various display mode ensures spot, multi-screen (4 / 16 split-screen display, 3 / 4 / 6 / 9 / 12 / 16 split-screen display on a full screen)
Various Recording Mode ensure Schedule, Event (Pre / Post)
Filtered search available for time and date, event type, camera number, and timeline
Recorded images can be downloaded to a PC
Downloadable viewer software allows playback of images downloaded from the recorder
Built-in network interface (10Base-T / 100Base-TX / 1000Base-T) for recording and client access
Up to 4 clients can monitor an image and control the WJ-NV200 simultaneously
Up to 2 HDDs (3.5" Serial ATA) can be installed (WJ-NV200 only)
User authentication, 3 user levels and User level-Camera partitioning setup for user management of up to 16 user registrations
Multi-recorder, Multi-site system can be made with the optional WV-ASM200 i-PRO Management Software
Onvif NVC (Network Video Client), core spec Ver.1.02 conformant
DVD drive built-in (WJ-NV200V)





Cameras

Supported Cameras
Panasonic i-PRO series Network cameras, and Onvif NVT-conformant camera and encoder camera
Image Format
H.264, MPEG-4, MJPEG
Image Resolution
Aspect ratio (4:3): SXVGA (1,280 x 960), SVGA (800 x 600), VGA (640 x 480), QVGA (320 x 240)
Aspect ratio (16:9): 1,920 x 1,080, 1,280 x 720, 640 x 360, 320 x 180
Audio Format
G.726 (ADPCM) 32 Kbps
Maximum Number of Cameras
16
Recording

Recording Mode
Event, schedule
Pre-alarm Record
Up to 15 seconds (up to 10 seconds at 1,920 x 1080 resolution)
Scheduled Recording
2 programs, 3 time zones/day, Independent setup for each day of the week
Frame Rate
Up to 30 ips (depending on the camera)
Main Unit

Camera Control
Pan / tilt, zoom, focus, brightness, preset position call and program (up to 256), functions auto mode, click centering, wheel zoom, zoom reset, auto back focus
Multi-Screen Display
4 / 16 split-screen display, 3 / 4 / 6 / 9 / 12 / 16 split-screen display on a full screen
Playback Control
Play, rev play, pause, stop, FF, FR, previous record, next record, previous image, next image, go to date, go to last (30 seconds)
Search Modes
Search criteria: Time date, playback by designating a timeline, VMD
Copy Features
Recorded data of selected cameras and time date range can be copied to the SD (SDHC) card
Camera Title
Up to 14 characters
Clock Display
Time: 12 / 24 H
Date: 5 formats
Digital Zoom
Live: 2x, 4x, 8x (only for 1-screen or 4-screen)
Play: 2x, 4x, 8x
System Log
Operator access (100), network error (100), error (1,000), event (750)
System Setup
Setup page in English, French, Italian, Spanish, German, Russian, Japanese
Browser GUI

Camera Control
Pan / tilt, zoom, focus, brightness, preset position call and program (up to 256), auto mode, click centering, wheel zoom, zoom reset
Playback Control
Record, play, rev play, pause, stop, FF, FR, previous record, next record, previous image, next image, go-to-date, go-to-last (30 seconds)
Search Modes
Search Criteria: Time date, event type, VMD, camera number
Display Mode
1 / 4 screen
Download
Image: Recorded data of the selected camera and time range can be downloaded to a PC. Viewer software can be downloaded separately
Copy Features
Recorded data of selected cameras and time date range can be copied to the SD (SDHC) card.
Camera Title
Up to 14 characters
Clock Display
On the browser
Time: 12 / 24 H
Date: 5 formats
Digital Zoom
Live / Play: 2x, 4x (only for 1-screen)
System Log
Operator access (100), Network error (100), Error (1,000), Event (750)
GUI Language
English, French, Italian, Spanish, German, Russian, Japanese
Supported OS
Microsoft Windows 7 Professional 64 bit/32 bit & Microsoft Windows Vista Business SP1 32 bit
Supported Web Browsers
Windows Internet Explorer 7.0 & 8.0
PC requirements
MJPEG/MPEG-4: Intel Core 2 Duo 2.66 GHz or faster (CPU), 1 GB or more (RAM), minimum 64 MB & maximum 128 MB or more (VRAM), Microsoft DirectX 9.0c or later

H.264: Intel Core i7-920 or faster (CPU), 3 GB or more (RAM), minimum 64 MB & maximum 128 MB or more (VRAM), Microsoft DirectX 9.0c or later
Alarm and Event

Alarm Source
9x terminal inputs, 16x camera alarms, Panasonic alarm protocol
Face Detection
Off / On
Event
Off / On
Alarm Actions
Alarm recording, email notification, alarm message, camera positioning, terminal output, Panasonic alarm protocol output, buzzer, and indicator
Alarm Control
Reset
Event Log
750
Input / Output

Connectors
Spot Output: 1x 1 Vpp / 75 Ω BNC
Monitor (HDMI): 1x HDMI
Audio Output: 1x −10 dBv, 600 Ω, Unbalanced (RCA)
Alarm/Control (25 pin D-sub): Alarm input 1 to 9, alarm output, alarm reset input, face matching output (alarm), time adjustment input, 5 V output (control)

Port
Mouse Connection: 1x Network: 1x 10 BASE-T / 100 BASE-TX / 1000 BASE-T (RJ-45)
Memory Card Slot
SDHC/SD memory cards applicable (miniSD cards and microSD cards not applicable)
Network

Networking Maximum Bandwidth
Total 80 Mbps or less
Supported Protocols
TCP/IP, UDP/IP, HTTP, FTP, SMTP, DNS, NTP, SNMP, and RTP
E-mail
Upon alarm or warning
Number of Users
4 or less (simultaneous users)
User Registration
Up to 16 users
User Levels
3 levels (Programmable)
Partitioning
User level, Camera (view & control, no access)
Security
User authentication (ID and password), alteration detection
Time Synchronization
Terminal (slave), NTP (server/client)
Time
Summer: User definable (using menu setup)
HDD Type
3.5" (88.9 mm) Serial ATA HDD up to 1x HDD can be installed
Disk Type
DVD: DVD-R, +R (Not supported: DVD-R DL, +R DL, DVD-R for authoring 8 cm disks)
Software

Playback Control
Play, rev play, pause, FF, FR, prev record, next record, prev image, and next image
Additional Functions
Alteration detection, save as JPEG, 2x zoom, print, and copy
Supported OS
Language: English, French, Italian, Spanish, German, Russian, Japanese; language of the software will be English
General

Safety/EMC Standard
UL (UL60065), FCC (Part15 ClassA), C-UL (CAN/CSA C22.2 No.60065), DOC (ICES003 ClassA)
Power Source
120 VAC, 60 Hz
Power Consumption
Approximately 45 W
Storage Capacity
3 TB (3 x 1 TB)
TV System
NTSC
Ambient Operating Temperature
Main body: 41 to 113°F (5 to 45°C)
Mouse (provided): 41 to 104°F (5 to 40°C)
Ambient Operating Humidity
10 to 80% (without condensation)
Maximum Operating Altitude
6,562' (2,000 m) above sea level
Dimensions
16.53 x 3.47 x 11.8" (420 x 88 x 300 mm) excluding rubber feet and projections
Weight
10.6 lb (4.8 kg) without HDD
12.36 lb (5.6 kg) with 1 HDD
