Condition: New Factory Sealed
Honeywell's MS9500 Voyager series of hand-held (single-line) laser scanners offers the user an aggressive solution for scanning all standard 1D bar codes including GS1 DataBar (RSS) bar codes. The MS9500 series is equipped with both in-stand and out-of-stand operation enabling hand-held or fixed projection scanning.
The MS9540, VoyagerCG incorporates Honeywell's patented auto-trigger and CodeGate button feature. When a bar code is place in the scanner's IR range, the auto-trigger activates the laser enabling the user to align the visible laser line over the bar code selected for scanning. The user can then press the CodeGate button, to transmit the data to the host system. When the MS9540 is placed in the stand the CodeGate button feature will automatically deactivating for hands free operation.
|
Main Features
|
| Barcode | ||||
| Barcodes: | China Post , Codabar , Code 11 , Code 128 , Code 2 of 5 , Code 32 , Code 39 , Code 93 , Code 93i , EAN-UCC Composite , EAN/JAN , GS1 DataBar , Interleaved 2 of 5 , Matrix 2 of 5 , MSI-Plessey , NW-7 , Telepen , Trioptic Code , UPC | |||
| Features: | CodeGate , Reduced Space Symbology (RSS) , Triggered | |||
| Interface: | USB | |||
| Light Source Wave Length: | 650 nm | |||
| Max Working Distance: | 10 in | |||
| Minimum Bar Width: | 5 mil | |||
| Pitch (Degrees): | 68 | |||
| Print Contrast Signal (PCS): | 35% | |||
| Skew (Degrees): | 52 | |||
| Cable | ||||
| Connectivity Details Type: | USB cable | |||
| Environmental Parameters | ||||
| Humidity Range Operating: | 5 - 95% (non-condensing) | |||
| Max Operating Temperature: | 104 °F | |||
| Min Operating Temperature: | 32 °F | |||
| Header | ||||
| Brand: | Honeywell | |||
| Compatibility: | PC | |||
| Manufacturer: | Honeywell | |||
| Model: | MS9540 VoyagerCG | |||
| Packaged Quantity: | 1 | |||
| Product Line: | Honeywell | |||
| Input Device | ||||
| Connectivity Technology: | Wired | |||
| Interface Type: | USB | |||
| OK Notification: | Beeper , LED indicator | |||
| TTL Decoding: | Decoded | |||
| Interface Required | ||||
| Connector Type: | Type A | |||
| Total Qty: | 1 | |||
| Type: | USB | |||
| Miscellaneous | ||||
| Color: | Black | |||
| Color Category: | Black | |||
| Compliant Standards: | cULus , EN 60825-1 , EN55022 Class B , FCC Part 15 B , ICES-003 Class B , IEC 825-1/EN 60825-1 class 1 , Laser Class 1 , RoHS , WEEE | |||
| Included Accessories: | Hard mount stand | |||
| Power Device | ||||
| Electric Current Required: | 120 mA (standby) , 165 mA (operating) | |||
| Scanner | ||||
| Form Factor: | Handheld | |||
| Scan Element Type: | Visible laser diode | |||
| Scan Mode: | Single-pass | |||
| Scan Speed: | 72 line / sec | |||
| Type: | Barcode scanner | |||
| Slot Required | ||||
| Type: | None | |||
| Dimensions & Weight | ||||
| Depth: | 2.2 in | |||
| Height: | 7.8 in | |||
| Weight: | 5.26 oz | |||
| Width: | 3.1 in | |||
| Cable Details | ||||
| Included Qty: | 1 | |||
| Shock & Vibration Tolerance | ||||
| Drop Specification: | 5 ft to concrete | |||
